Opticstar AR80S Guidescope

Guidescope complete with collimating rings and dovetail.

Aperture: 80mm
Focal Length: 400mm (f/5)
Optical Coatings: Fully Multi Coated
2-inch Crayford focuser
Retractable dewshield
Collimating rings
Vixen-style dovetail
UK warranty

Opticstar AR80S Guidescope

Product code: AR80SGS
Availability: Not in production
Not available
Original Price: £

Shipping rates: England & Wales

£ 10.00

Scotland Central & South

£ 10.00

Scotland North

£ 20.00

UK islands (from)

£ 30.00

Description

The AR80S Guidescope kit consists of the Opticstar AR80S telescope, set of collimating rings and Vixen-type dovetail to mount the telescope to standard mount saddles as found on the Meade, Sky-Watcher, Celestron, Vixen and other mounts.

The Opticstar AR80S Gold short-tube refractor is ideal as a portable scope and can be used for observing, imaging or as a guide scope. It uses an 80mm achromatic doublet that is fully broad-band multicoated to increase light transmission.

The optical tube greatly benefits from metal knife-edge baffles (not the plastic less effective step type) that prevent stray light outside the field of view from reaching the focal plane. Knife-edge baffles markedly increase image contrast.

U.K. WARRANTY

INTERMEDIATE

PORTABLE

TERRESTRIAL

ASTRONOMY

PHOTOGRAPHY

▼ read more ▼

The Crayford focuser, main tube and lens assembly are screwed into each other for maximum rigidity, no peripheral screws are used as they can compromise the rigidity of the telescope.

The AR80S Gold refractor features a smooth Crayford focuser with a 2” drawtube (with 1.25" adapter), retractable metal dew shield, CNC rings with 1/4" photo tripod threads, and broadband fully multi-coated optics.

With a focal length of 400mm (f/5) the AR80S is very well suited for wide field astrophotography, guiding as well as nature photography.

With a minimum total length of only 40cm and 80mm aperture the AR80S Gold is the perfect travel scope. All you need to start using the AR80S Gold is a photographic tripod, diagonal and eyepieces.

Carries full one year UK warranty.

Opticstar AR80S Guidescope.

▲ read less ▲

▼ show specification ▼

Opticstar AR80S Guidescope
Attribute	Specification
Opticstar Product Code / sku	AR80SGS
Universal Product Code (UPC)	n/a
Warranty	1 year UK warranty
Series	AR
Experience Level	Intermediate
Clear Aperture	80mm
Focal Length	400mm
Focal Ratio	f/5
Optical Design	Achromatic doublet refractor
Optical Elements	2-elements
Optical Coatings	Broadband FMC (fully multi-coated)
Focuser	Single-speed Crayford focuser
Focuser Drawtube	2-inch with 1.25-inch adapter
Focuser Tube Travel	70mm (marked in 1mm intervals)
Baffles	Internally anti-reflection coated, knife-edge baffles
Construction	All metal construction
Dew Shield	Retractable with metal screw-type cap
Tube Rings	Collimating rings
Dovetail	Vixen-style
Finderscope Saddle	No
Case	No
Tube Design	Short
Tube Weight	2 kg (including rings)
Minimum Tube Length	310mm with retracted dew-shield
Maximum Tube Length	365mm with extended dew-shield
Tube Diameter	97mm
Frontal Dewshield Diameter	110mm (screw-type aluminium cap)

▲ hide specification ▲

Support

Documents: Opticstar AR80S Guidescope user guide

0.3 MB • 25 March 2014

Opticstar AR telescopes

0.8 MB • 25 March 2014

Meade and Coronado catalogue

19.3 MB • 05 February 2021

Meade Instruments UK warranty

0.1 MB • 12 October 2021

GPDR (General Data Protection Regulation)

0.2 MB • 12 October 2021

Astro images: Imaged with Opticstar AR80S telescope
Links: Opticstar optical tube assemblies (OTAs)

internal link • optical tube series page
